Model: | CH-F1600 |
Voltage: | AC380V/50Hz |
Output power: | 3000W |
Fusing width: | 1600mm |
Fusing speed: | 0-60m/min |
Fusing tempreture: | 300℃ |
Pneumatic pressure: | 6 Kg/cm2 |
Belt thickness: | 0.5 mm |
Machine dimension: | 2200 x 1750 x 1450mm |
Net Weight: | 700 Kg |
Inquiry |
Specification:
Specification:
1,Automatic cooling device: equipped with timed automatic cooling stop switch system
2, The heating temperature is uniform: the professional device intelligently controls the temperature
difference to the minimum, the heating zone temperature difference is not more than ± 5 ° C
3, Unlimited object length: continuous bonding, calendering stereotypes are not subject to object length
4. Automatic belt correction: equipped with imported micro-
motion omron switch to eliminate belt deviation and ensure belt service life.
5, Cooling and fast setting: equipped with 3200 rpm fan and mesh belt conveyor system, cooling speed,
fabric bonding and shaping effect is good
6. The pressure of the rubber roller is stable: the pressure is even within the width of the tape, and the
diameter of the upper and lower rubber shaft is 100MM.
7. Stable heating system: composed of up and down nine aluminum plates
8, the speed is flexible and adjustable: install the inverter to adjust the speed
